E500 is a light-weight tilt-featured product by eSurvey GNSS. The durable IP67 design makes it possible to work in various of environments. Multi constellation and frequency tracking always gives a Fixed solution for your job. Thanks for the small-size design, E500 is suitable for different applications such as car and machine control.
1.
Multi-constellation
and Multi-frequency
With
800 channels of GNSS tracking, E500 provides stable and reliable accuracy. All
GNSS signals are coming with standard including GPS, BDS, GLONASS, GALILEO,
QZSS, IRNSS and SBAS.
2.
Intelligent
Battery LED Indicators
Without
powering on device, it is able to check the battery level on the battery LED
indicators by simply clicking the power button.
3.
MEMS
Dynamic Tilt Survey
eSurvey’s
innovation tilt survey solution provides a surprising experience. The sensor is
adapted to various of working environments and can be ready within 10 sec. Maximum
60° incline angle ensures a tilt-to-go survey without
stopping your work.
4.
L-band
Atlas
Atlas
is a service to provide global precision correction service over L-band
satellites. With ATLAS subscription, E500 is able to achieve centimeter
accuracy without any base station.
5. aRTK
Powered
by Atlas, the innovative aRTK technology operates on any Atlas-capable device
by enabling it to maintain RTK-level accuracy, availability, and reliability
when RTK corrections fail without additional cost.
6. Web
UI
It
is able to view position status, set up working mode, download data and update
firmware from Web user interface with any phone, tablet or PC.
7.
Intelligent
Voice
E500
will broadcast voice automatically to remind user the solution status is
changed. It is also able to manually broadcast current working mode and
solution status by short pressing power button.
8.
Rugged
Design
E500
main body is using magnesium materials to provide strong shock and vibration
resistant characteristics. IP67 certification ensures operation in various of
tough environments.
GNSS |
|
Satellites Tracking |
GPS: L1CA/L1P/L1C/L2P/L2C/L5 BDS: B1I/B2I/B3I/B1C/B2a/B2b/ ACEBOC GLONASS: G1/G2/G3, P1/P2 GALILEO: E1/E5a/E5b/E6/ALTBOC QZSS: L1CA/L1C/L2C/L5/LEX IRNSS: L5 |
Channels |
800 |
Signal Reacquisition |
< 1 sec |
Cold Start |
< 60 sec |
Warm Start |
< 30 sec |
Hot Start |
< 10 sec |
RTK Signal Initialization |
< 8 sec |
Initialization Reliability |
> 99.9% |
Update Rate |
10 Hz standard, up to 50 Hz |
Operation System |
Linux |
Internal Memory |
8 GB |
Performance |
|
High Precision Static |
H: 2 mm + 0.1 ppm V: 3 mm + 0.4 ppm |
Static/Fast Static |
H: 2.5 mm + 0.1 ppm V: 3.5 mm + 0.4 ppm |
RTK |
H: 8 mm + 1 ppm V: 15 mm + 1 ppm |
Code Differential |
H: 0.25 m V: 0.45 m |
SBAS |
H: 0.3 m V: 0.6 m |
L-Band |
Atlas H10: 4 cm RMS Atlas H30: 15 cm RMS Atlas Basic: 30 cm RMS |
Power
Supply |
|
Battery |
Rechargeable and built-in Lithium-ion
battery, 7.2 V ~ 6800 mAh |
Voltage |
9~28 VDC with over-voltage protection |
Working Time |
Up to 12 hours |
Charging Time |
Typically 4 hours |
Internal
Radio |
|
Type |
TX and RX |
Frequency Range |
410 ~ 470 MHz, 902.4 ~ 928 MHz |
Channel Spacing |
12.5 KHz / 25 KHz |
Emitting Power |
1 W |
Operation Range |
3 ~ 5 Km typically 10 Km with optimal conditions |
Protocol |
Satel, PCC, TrimTalk, TrimMark III,
South, HiTarget |
Internet
Modem |
|
Support Band |
Global GSM /WCDMA/LTE |
Communication |
|
Bluetooth |
BT 5.0 + EDR, BLE |
WIFI |
802.11 b/g/n |
SIM Card |
SIM card |
5-pin Port |
Connect to external radio and power, NMEA output |
Type-C Port |
Charge and internal storage access |
TNC Port |
Connect to internal radio antenna |
Web UI |
View status, update firmware, set up
working mode, download data |
Intelligent Voice |
Broadcast working status |
NMEA Output |
GGA, ZDA, GSA, GSV, GST, VTG, RMC, GLL,
Binary |
Correction Data |
CMR, CMR+, RTCM2, RTCM3, RTCM32 |
MEMS |
Fast initialization, dynamic tilt
survey up to 60° |
Physical |
|
Dimension |
Φ148 mm x H74.5 mm |
Weight |
1.06 kg |
Operating Temperature |
-40℃ ~ +65℃ |
Storage Temperature |
-45℃ ~ +80℃ |
Water/Dust Proof |
IP67 |
Shock |
Survive a 2 m drop on concrete floor |
Vibration |
Vibration resistant |
Humidity |
Up to 100% |
Indicators |
Battery |
Button |
Power button |
Certificate |
CE, FCC, NGS Calibration |
