iF Design Award Product

A global symbol of excellent design - especially with hosting. One of the most prestigious design awards worldwide.

Battery Indicator: An Intelligent Hint of Working Time

Quickly check the remaining battery power in real-time and figure out the working time without data loss.

Integrated Tx/Rx UHF Modem

The built-in transceiver radio modem, compatible with major radio protocols, allows the E500 to work as a base or rover station.

Max 60° Tilt Survey: A Different Way of Working

·  Quickly measure accurate points while standing or walking without leveling the pole.

·  Concentrate on where the pole tip needs to go, which is especially useful during a stakeout.

·  Easily start a survey in environments that are hard to reach, such as building corners and slopes.

·  No longer worry about the movement of the pole when measuring, provided that the pole tip is stationary.

Rugged Design: Better Resistance to Shock and Fall

Use it for many years, for it is strongly made and capable of withstanding rough handling.

RTK Aid Function: Uninterrupted Work

Work without interruption even when RTK corrections fail, powered by our RTK aid function.
